Apem Inc. TL49Y000000
- Mfg. Part Number
- TL49Y000000
- Manufacturer
- Apem Inc.
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE DPDT 0.4VA 20V
- Datasheet Download
- TL49Y000000.pdf
Availability of TL49Y000000
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.63950
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TL49Y000000, we specialize in Apem Inc. all series electronic components. TL49Y000000 can be shipped within 24 hours after order. If you have any demands for TL49Y000000, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TL49Y000000 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TL49Y000000
| Internal Part Number | EIS-TL49Y000000 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 100 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | TL | |
| Packaging | Bulk | |
| Circuit | DPDT | |
| Switch Function | On-Off-On | |
| Current Rating | 0.4VA (AC/DC) | |
| Voltage Rating - AC | 20V | |
| Voltage Rating - DC | 20V | |
| Actuator Type | Standard Round | |
| Actuator Length | 5.30mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Panel Cutout Dimensions | - | |
| Bushing Thread | Unthreaded | |
| Ingress Protection | - | |
| Features | Epoxy Sealed Terminals | |
| Actuator Material | Brass, Nickel Plated | |
| Electrical Life | 30,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TL49Y000000 | |
| Related Links | TL49Y, TL49Y000000 Datasheet, Apem Inc. Distributor | |
TL49Y000000 Details Description
