Texas Instruments TLC3574IDWG4
- Mfg. Part Number
- TLC3574IDWG4
- Manufacturer
- Texas Instruments
- Product Category
- Data Acquisition - Analog to Digital Converters (ADC)
- Brief Description
- IC ADC 14BIT 200KSPS 4CH 20-SOIC
- Datasheet Download
- TLC3574IDWG4.pdf
Availability of TLC3574IDWG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 12.16750
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TLC3574IDWG4, we specialize in Texas Instruments all series electronic components. TLC3574IDWG4 can be shipped within 24 hours after order. If you have any demands for TLC3574IDWG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TLC3574IDWG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TLC3574IDWG4
| Internal Part Number | EIS-TLC3574IDWG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Data Converter Basics | |
| Manufacturer Product Page | TLC3574IDWG4 Specifications | |
| Standard Package | 25 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Analog to Digital Converters (ADC) | |
| Series | - | |
| Packaging | Tube | |
| Number of Bits | 14 | |
| Sampling Rate (Per Second) | 200k | |
| Number of Inputs | 2, 4 | |
| Input Type | Pseudo-Differential, Single Ended | |
| Data Interface | SPI | |
| Configuration | MUX-S/H-ADC | |
| Ratio - S/H:ADC | 1:1 | |
| Number of A/D Converters | 1 | |
| Architecture | SAR | |
| Reference Type | External | |
| Voltage - Supply, Analog | 5V | |
| Voltage - Supply, Digital | 2.7 V ~ 5.5 V | |
| Features | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 20-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TLC3574IDWG4 | |
| Related Links | TLC357, TLC3574IDWG4 Datasheet, Texas Instruments Distributor | |
TLC3574IDWG4 Details Description
