Texas Instruments TLC7701IDRG4
- Mfg. Part Number
- TLC7701IDRG4
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Supervisors
- Brief Description
- IC 1.1V SUPPLY MONITOR 8-SOIC
- Datasheet Download
- TLC7701IDRG4.pdf
Availability of TLC7701IDRG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.72360
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TLC7701IDRG4, we specialize in Texas Instruments all series electronic components. TLC7701IDRG4 can be shipped within 24 hours after order. If you have any demands for TLC7701IDRG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TLC7701IDRG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TLC7701IDRG4
| Internal Part Number | EIS-TLC7701IDRG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Supervisors | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Simple Reset/Power-On Reset | |
| Number of Voltages Monitored | 1 | |
| Output | Push-Pull, Totem Pole | |
| Reset | Active High/Active Low | |
| Reset Timeout | 1.1 ms Minimum | |
| Voltage - Threshold | 1.1V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TLC7701IDRG4 | |
| Related Links | TLC770, TLC7701IDRG4 Datasheet, Texas Instruments Distributor | |
TLC7701IDRG4 Details Description
