Infineon Technologies TLE49612MXTSA1
- Mfg. Part Number
- TLE49612MXTSA1
- Manufacturer
- Infineon Technologies
- Product Category
- Magnetic Sensors - Hall Effect, Digital Switch, Linear, Compass (ICs)
- Brief Description
- IC HALL EFFECT LATCH SOT23-3
- Datasheet Download
- TLE49612MXTSA1.pdf
Availability of TLE49612MXTSA1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.30979
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TLE49612MXTSA1, we specialize in Infineon Technologies all series electronic components. TLE49612MXTSA1 can be shipped within 24 hours after order. If you have any demands for TLE49612MXTSA1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TLE49612MXTSA1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TLE49612MXTSA1
| Internal Part Number | EIS-TLE49612MXTSA1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Packaging | Carrier Tape Update 03/Jun/2015 | |
| Standard Package | 3,000 | |
| Category | Sensors, Transducers | |
| Family | Magnetic Sensors - Hall Effect, Digital Switch, Linear, Compass (ICs) | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Sensing Range | 5mT Trip, -5mT Release | |
| Type | Bipolar Latch | |
| Voltage - Supply | 3 V ~ 32 V | |
| Current - Supply | 2.5mA | |
| Current - Output (Max) | 25mA | |
| Output Type | Open Drain | |
| Features | - | |
| Operating Temperature | -40°C ~ 170°C | |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | |
| Supplier Device Package | PG-SOT23-3-15 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TLE49612MXTSA1 | |
| Related Links | TLE4961, TLE49612MXTSA1 Datasheet, Infineon Technologies Distributor | |
