Infineon Technologies TLE8444SL
- Mfg. Part Number
- TLE8444SL
- Manufacturer
- Infineon Technologies
- Product Category
- PMIC - Motor Drivers, Controllers
- Brief Description
- IC MOTOR DRIVER PAR 24SSOP
- Datasheet Download
- TLE8444SL.pdf
Availability of TLE8444SL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.14689
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TLE8444SL, we specialize in Infineon Technologies all series electronic components. TLE8444SL can be shipped within 24 hours after order. If you have any demands for TLE8444SL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TLE8444SL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TLE8444SL
| Internal Part Number | EIS-TLE8444SL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Motor Drivers, Controllers | |
| Series | - | |
| Motor Type - Stepper | Bipolar | |
| Motor Type - AC, DC | Brushed DC | |
| Function | Driver - Fully Integrated, Control and Power Stage | |
| Output Configuration | Half Bridge (4) | |
| Interface | Parallel | |
| Technology | BiCDMOS | |
| Step Resolution | - | |
| Applications | Automotive | |
| Current - Output | 1A | |
| Voltage - Supply | 8 V ~ 18 V | |
| Voltage - Load | 8 V ~ 18 V | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 24-SSOP (0.154", 3.90mm Width) | |
| Supplier Device Package | PG-SSOP-24 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TLE8444SL | |
| Related Links | TLE8, TLE8444SL Datasheet, Infineon Technologies Distributor | |
TLE8444SL Details Description
