Taiyo Yuden TLF14CB5630R2
- Mfg. Part Number
- TLF14CB5630R2
- Manufacturer
- Taiyo Yuden
- Product Category
- Common Mode Chokes
- Brief Description
- CHOKE COMMON MODE 56000UH
- Datasheet Download
- TLF14CB5630R2.pdf
Availability of TLF14CB5630R2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TLF14CB5630R2, we specialize in Taiyo Yuden all series electronic components. TLF14CB5630R2 can be shipped within 24 hours after order. If you have any demands for TLF14CB5630R2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TLF14CB5630R2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TLF14CB5630R2
| Internal Part Number | EIS-TLF14CB5630R2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 500 | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Series | TLF | |
| Packaging | Bulk | |
| Filter Type | Power Line | |
| Number of Lines | 2 | |
| Inductance | 56mH | |
| Current | 200mA | |
| DC Resistance (DCR) | 5 Ohm Max | |
| Impedance | - | |
| Operating Temperature | -25°C ~ 105°C | |
| Mounting Type | Through Hole | |
| Size / Dimension | 0.867" L x 0.669" W (22.00mm x 17.00mm) | |
| Height (Max) | 0.906" (23.00mm) | |
| Package / Case | Vertical, 4 PC Pin | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TLF14CB5630R2 | |
| Related Links | TLF14C, TLF14CB5630R2 Datasheet, Taiyo Yuden Distributor | |
TLF14CB5630R2 Details Description
