C&K Components TMCGD6ST1340C
- Mfg. Part Number
- TMCGD6ST1340C
- Manufacturer
- C&K Components
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SWITCH SNAP ACTION
- Datasheet Download
- TMCGD6ST1340C.pdf
Availability of TMCGD6ST1340C
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.75920
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TMCGD6ST1340C, we specialize in C&K Components all series electronic components. TMCGD6ST1340C can be shipped within 24 hours after order. If you have any demands for TMCGD6ST1340C, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TMCGD6ST1340C Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TMCGD6ST1340C
| Internal Part Number | EIS-TMCGD6ST1340C | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | TM | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 10A (AC), 500mA (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 125V | |
| Actuator Type | Lever, Simulated Roller | |
| Mounting Type | Chassis Mount | |
| Termination Style | Quick Connect - 0.187" (4.7mm) | |
| Ingress Protection | - | |
| Features | - | |
| Operating Force, Torque | 45gf | |
| Release Force | 10gf | |
| Pretravel | 0.161" (4.1mm) | |
| Differential Travel | 0.030" (0.76mm) | |
| Overtravel | 0.065" (1.7mm) | |
| Operating Position | 0.812" (20.6mm) | |
| Mechanical Life | - | |
| Electrical Life | 350,000 Cycles | |
| Operating Temperature | -55°C ~ 150°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TMCGD6ST1340C | |
| Related Links | TMCGD6, TMCGD6ST1340C Datasheet, C&K Components Distributor | |
TMCGD6ST1340C Details Description
