Texas Instruments TMS470R1A384PZ-T
- Mfg. Part Number
- TMS470R1A384PZ-T
- Manufacturer
- Texas Instruments
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU ARM7 384KB FLASH 100LQFP
- Datasheet Download
- TMS470R1A384PZ-T.pdf
Availability of TMS470R1A384PZ-T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 14.35600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TMS470R1A384PZ-T, we specialize in Texas Instruments all series electronic components. TMS470R1A384PZ-T can be shipped within 24 hours after order. If you have any demands for TMS470R1A384PZ-T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TMS470R1A384PZ-T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TMS470R1A384PZ-T
| Internal Part Number | EIS-TMS470R1A384PZ-T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Intro to Timers and Clocks Microcontrollers: SYS/BIOS: Introduction to Real-Time Operating Systems and SYS/BIOS | |
| Design Resources | Development Tool Selector | |
| PCN Assembly/Origin | Qualification Copper Wire 22/Jul/2014 | |
| PCN Packaging | 14x14x1.4 LQFP Tray Update 26/Sep/2013 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 90 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | TMS470 | |
| Packaging | Tray | |
| Core Processor | ARM7® | |
| Core Size | 16/32-Bit | |
| Speed | 48MHz | |
| Connectivity | CAN, C2Slb, I²C, SCI, SPI | |
| Peripherals | DMA, PWM, WDT | |
| Number of I/O | 53 | |
| Program Memory Size | 384KB (384K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 32K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.71 V ~ 2.05 V | |
| Data Converters | A/D 12x10b | |
| Oscillator Type | External | |
| Operating Temperature | -40°C ~ 105°C | |
| Package / Case | 100-LQFP | |
| Supplier Device Package | 100-LQFP (14x14) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TMS470R1A384PZ-T | |
| Related Links | TMS470R1, TMS470R1A384PZ-T Datasheet, Texas Instruments Distributor | |
TMS470R1A384PZ-T Details Description
