Vishay/Dale TNPW08052K80BEEA
-TNP-SERIES.jpg)
- Mfg. Part Number
- TNPW08052K80BEEA
- Manufacturer
- Vishay/Dale
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 2.8K OHM 0.1% 1/8W 0805
- Datasheet Download
- TNPW08052K80BEEA.pdf
Availability of TNPW08052K80BEEA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.16964
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TNPW08052K80BEEA, we specialize in Vishay/Dale all series electronic components. TNPW08052K80BEEA can be shipped within 24 hours after order. If you have any demands for TNPW08052K80BEEA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TNPW08052K80BEEA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TNPW08052K80BEEA
| Internal Part Number | EIS-TNPW08052K80BEEA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | High-Stability Thin-Film Flat Chip Resistors | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 5,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | TNPW | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 2.8k | |
| Tolerance | ±0.1% | |
| Power (Watts) | 0.125W, 1/8W | |
| Composition | Thin Film | |
| Features | Anti-Sulfur, Automotive AEC-Q200, Moisture Resistant | |
| Temperature Coefficient | ±25ppm/°C | |
| Operating Temperature | -55°C ~ 125°C | |
| Package / Case | 0805 (2012 Metric) | |
| Supplier Device Package | 0805 | |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) | |
| Height | 0.022" (0.55mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TNPW08052K80BEEA | |
| Related Links | TNPW0805, TNPW08052K80BEEA Datasheet, Vishay/Dale Distributor | |
TNPW08052K80BEEA Details Description
