Vishay/Dale TNPW0805511RBEEN
-TNP-SERIES.jpg)
- Mfg. Part Number
- TNPW0805511RBEEN
- Manufacturer
- Vishay/Dale
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 511 OHM 0.1% 1/8W 0805
- Datasheet Download
- TNPW0805511RBEEN.pdf
Availability of TNPW0805511RBEEN
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.31050
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TNPW0805511RBEEN, we specialize in Vishay/Dale all series electronic components. TNPW0805511RBEEN can be shipped within 24 hours after order. If you have any demands for TNPW0805511RBEEN, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TNPW0805511RBEEN Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TNPW0805511RBEEN
| Internal Part Number | EIS-TNPW0805511RBEEN | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | High-Stability Thin-Film Flat Chip Resistors | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | TNPW | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 511 | |
| Tolerance | ±0.1% | |
| Power (Watts) | 0.125W, 1/8W | |
| Composition | Thin Film | |
| Features | Anti-Sulfur, Automotive AEC-Q200, Moisture Resistant | |
| Temperature Coefficient | ±25ppm/°C | |
| Operating Temperature | -55°C ~ 125°C | |
| Package / Case | 0805 (2012 Metric) | |
| Supplier Device Package | 0805 | |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) | |
| Height | 0.022" (0.55mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TNPW0805511RBEEN | |
| Related Links | TNPW0805, TNPW0805511RBEEN Datasheet, Vishay/Dale Distributor | |
