Power Integrations TOP222PN
- Mfg. Part Number
- TOP222PN
- Manufacturer
- Power Integrations
- Product Category
- PMIC - AC DC Converters, Offline Switchers
- Brief Description
- IC OFFLINE SWIT PWM OCP HV 8DIP
- Datasheet Download
- TOP222PN.pdf
Availability of TOP222PN
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.33200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TOP222PN, we specialize in Power Integrations all series electronic components. TOP222PN can be shipped within 24 hours after order. If you have any demands for TOP222PN, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TOP222PN Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TOP222PN
| Internal Part Number | EIS-TOP222PN | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - AC DC Converters, Offline Switchers | |
| Series | TOPSwitch®-II | |
| Packaging | Tube | |
| Output Isolation | Isolated | |
| Internal Switch(s) | Yes | |
| Voltage - Breakdown | 700V | |
| Topology | Boost, Buck, Flyback, Forward | |
| Voltage - Start Up | - | |
| Voltage - Supply (Vcc/Vdd) | - | |
| Duty Cycle | 67% | |
| Frequency - Switching | 100kHz | |
| Power (Watts) | 15W | |
| Fault Protection | Current Limiting, Over Temperature | |
| Control Features | - | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Package / Case | 8-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 8-DIP | |
| Mounting Type | Through Hole | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TOP222PN | |
| Related Links | TOP2, TOP222PN Datasheet, Power Integrations Distributor | |
