C&K Components TP21MS9ABE
- Mfg. Part Number
- TP21MS9ABE
- Manufacturer
- C&K Components
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSH DPST-NO 0.4VA 20V
- Datasheet Download
- TP21MS9ABE.pdf
Availability of TP21MS9ABE
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.53580
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TP21MS9ABE, we specialize in C&K Components all series electronic components. TP21MS9ABE can be shipped within 24 hours after order. If you have any demands for TP21MS9ABE, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TP21MS9ABE Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TP21MS9ABE
| Internal Part Number | EIS-TP21MS9ABE | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | TP, T, TS Material 01/Jul/2009 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | TP | |
| Packaging | Bulk | |
| Type | Standard | |
| Circuit | DPST-NO | |
| Switch Function | Off-Mom | |
| Current Rating | 0.4VA (AC/DC) | |
| Voltage Rating - AC | 20V | |
| Voltage Rating - DC | 20V | |
| Actuator Type | Round, Plunger | |
| Color - Actuator/Cap | Black | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Through Hole, Right Angle | |
| Termination Style | PC Pin | |
| Ingress Protection | - | |
| Features | Epoxy Sealed Terminals | |
| Panel Cutout Dimensions | - | |
| Operating Temperature | -30°C ~ 85°C | |
| Mechanical Life | - | |
| Electrical Life | 60,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TP21MS9ABE | |
| Related Links | TP21M, TP21MS9ABE Datasheet, C&K Components Distributor | |
TP21MS9ABE Details Description
