Texas Instruments TPS2021DG4
- Mfg. Part Number
- TPS2021DG4
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Power Distribution Switches, Load Drivers
- Brief Description
- IC 0.9A PWR DIST SWITCH 8-SOIC
- Datasheet Download
- TPS2021DG4.pdf
Availability of TPS2021DG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.91200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TPS2021DG4, we specialize in Texas Instruments all series electronic components. TPS2021DG4 can be shipped within 24 hours after order. If you have any demands for TPS2021DG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TPS2021DG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TPS2021DG4
| Internal Part Number | EIS-TPS2021DG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 75 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Series | - | |
| Packaging | Tube | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | High Side | |
| Output Type | N-Channel | |
| Interface | On/Off | |
| Voltage - Load | 2.7 V ~ 5.5 V | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 600mA | |
| Rds On (Typ) | 33 mOhm | |
| Input Type | Non-Inverting | |
| Features | Status Flag | |
| Fault Protection | Current Limiting (Fixed), Over Temperature, UVLO | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TPS2021DG4 | |
| Related Links | TPS20, TPS2021DG4 Datasheet, Texas Instruments Distributor | |
