Thomas Research Products TRC-025S035PS
- Mfg. Part Number
- TRC-025S035PS
- Manufacturer
- Thomas Research Products
- Product Category
- LED Supplies
- Brief Description
- LED SUPPLY CC AC/DC 24-72V 350MA
- Datasheet Download
- TRC-025S035PS.pdf
Availability of TRC-025S035PS
Available Quantity
5023 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 40.24580
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TRC-025S035PS, we specialize in Thomas Research Products all series electronic components. TRC-025S035PS can be shipped within 24 hours after order. If you have any demands for TRC-025S035PS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TRC-025S035PS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TRC-025S035PS
| Internal Part Number | EIS-TRC-025S035PS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | LED Drivers Overview | |
| Design Resources | Lighting Product Selector | |
| 3D Model | VLED-25W, TRC-025.stpVLED-25W, TRC-025.igs | |
| Standard Package | 1 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | LED Supplies | |
| Series | TRC | |
| Type | Constant Current | |
| Topology | AC DC Converter | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 90VAC | |
| Voltage - Input (Max) | 305VAC | |
| Voltage - Output | 24 ~ 72 V | |
| Current - Output (Max) | 350mA | |
| Power (Watts) | 25W | |
| Voltage - Isolation | - | |
| Dimming | - | |
| Features | OCP, OVP, SCP | |
| Ratings | IP66 | |
| Operating Temperature | -20°C ~ 70°C | |
| Efficiency | 84% | |
| Termination Style | Wire Leads | |
| Size / Dimension | 3.07" L x 3.15" W x 1.02" H (78.0mm x 80.0mm x 26.0mm) | |
| Mounting Type | Chassis Mount | |
| Approvals | CE, cULus, EN | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TRC-025S035PS | |
| Related Links | TRC-02, TRC-025S035PS Datasheet, Thomas Research Products Distributor | |
TRC-025S035PS Details Description
