TE Connectivity Alcoswitch Switches TT41NGPC1
- Mfg. Part Number
- TT41NGPC1
- Manufacturer
- TE Connectivity Alcoswitch Switches
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE 4PDT 3A 125V
- Datasheet Download
- TT41NGPC1.pdf
Availability of TT41NGPC1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 20.94300
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TT41NGPC1, we specialize in TE Connectivity Alcoswitch Switches all series electronic components. TT41NGPC1 can be shipped within 24 hours after order. If you have any demands for TT41NGPC1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TT41NGPC1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TT41NGPC1
| Internal Part Number | EIS-TT41NGPC1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | TT41NGPC1 Statement of ComplianceRoHS 2 Statement | |
| Standard Package | 250 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | TT | |
| Packaging | Bulk | |
| Circuit | 4PDT | |
| Switch Function | On-On | |
| Current Rating | 3A (AC/DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Standard Round | |
| Actuator Length | 5.61mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Panel Cutout Dimensions | - | |
| Bushing Thread | Unthreaded | |
| Ingress Protection | - | |
| Features | - | |
| Actuator Material | Brass, Nickel Plated | |
| Electrical Life | 20,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TT41NGPC1 | |
| Related Links | TT41, TT41NGPC1 Datasheet, TE Connectivity Alcoswitch Switches Distributor | |
TT41NGPC1 Details Description
