Tamura TTC-13
- Mfg. Part Number
- TTC-13
- Manufacturer
- Tamura
- Product Category
- Audio Transformers
- Brief Description
- TRANSF TELE COUP 4000:600 0 MADC
- Datasheet Download
- TTC-13.pdf
Availability of TTC-13
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.15200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TTC-13, we specialize in Tamura all series electronic components. TTC-13 can be shipped within 24 hours after order. If you have any demands for TTC-13, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TTC-13 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TTC-13
| Internal Part Number | EIS-TTC-13 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 560 | |
| Category | Transformers | |
| Family | Audio Transformers | |
| Series | TTC | |
| Transformer Type | Data/Voice Coupling | |
| Current | - | |
| Impedance | 4k Primary, 600 Secondary | |
| Insertion Loss | 0.9dB Typ. | |
| Mounting Type | Through Hole | |
| Size / Dimension | 20.30mm L x 16.50mm W | |
| Height - Seated (Max) | 18.70mm | |
| Termination Style | PC Pin | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TTC-13 | |
| Related Links | TTC, TTC-13 Datasheet, Tamura Distributor | |
