Panasonic Electric Works TX2-LT-2.4V-TH
- Mfg. Part Number
- TX2-LT-2.4V-TH
- Manufacturer
- Panasonic Electric Works
- Product Category
- Power Relays, Over 2 Amps
- Brief Description
- RELAY GEN PURPOSE DPDT 2A 2.4V
- Datasheet Download
- TX2-LT-2.4V-TH.pdf
Availability of TX2-LT-2.4V-TH
Available Quantity
5035 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.91200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TX2-LT-2.4V-TH, we specialize in Panasonic Electric Works all series electronic components. TX2-LT-2.4V-TH can be shipped within 24 hours after order. If you have any demands for TX2-LT-2.4V-TH, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TX2-LT-2.4V-TH Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TX2-LT-2.4V-TH
| Internal Part Number | EIS-TX2-LT-2.4V-TH | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | T-Series Relays, Cautions for Use Relay Technical Info Standards Chart How to Read Date Codes | |
| Product Training Modules | Signal Relays | |
| Standard Package | 40 | |
| Category | Relays | |
| Family | Power Relays, Over 2 Amps | |
| Series | TX-TH | |
| Packaging | Tube | |
| Relay Type | General Purpose | |
| Coil Type | Latching, Dual Coil | |
| Coil Current | 58.3mA | |
| Coil Voltage | 2.4VDC | |
| Contact Form | DPDT (2 Form C) | |
| Contact Rating (Current) | 2A | |
| Switching Voltage | 250VAC, 220VDC - Max | |
| Turn On Voltage (Max) | 1.8 VDC | |
| Turn Off Voltage (Min) | - | |
| Operate Time | 4ms | |
| Release Time | 4ms | |
| Features | 7.5A Inrush, Sealed-Fully | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Contact Material | Silver (Ag), Gold (Au) | |
| Coil Power | 140 mW | |
| Coil Resistance | 41 Ohms | |
| Operating Temperature | -40°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TX2-LT-2.4V-TH | |
| Related Links | TX2-LT-, TX2-LT-2.4V-TH Datasheet, Panasonic Electric Works Distributor | |
TX2-LT-2.4V-TH Details Description
