TE Connectivity Aerospace, Defense and Marine TXR40AC45-1206AI
- Mfg. Part Number
- TXR40AC45-1206AI
- Manufacturer
- TE Connectivity Aerospace, Defense and Marine
- Product Category
- Circular Connectors - Backshells and Cable Clamps
- Brief Description
- CONN BACKSHELL ADPT SZ 13C SLVR
- Datasheet Download
- TXR40AC45-1206AI.pdf
Availability of TXR40AC45-1206AI
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 196.80000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TXR40AC45-1206AI, we specialize in TE Connectivity Aerospace, Defense and Marine all series electronic components. TXR40AC45-1206AI can be shipped within 24 hours after order. If you have any demands for TXR40AC45-1206AI, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TXR40AC45-1206AI Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TXR40AC45-1206AI
| Internal Part Number | EIS-TXR40AC45-1206AI | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors - Backshells and Cable Clamps | |
| Series | TXR | |
| Type | Backshell, Heat Shrink Adapter | |
| Cable Opening | - | |
| Diameter - Outside | 0.964" (24.50mm) | |
| Shell Size - Insert | 13, C | |
| Thread Size | M18x1 | |
| Cable Exit | 45° | |
| Material | Aluminum Alloy | |
| Plating | Electroless Nickel | |
| Shielding | Shielded | |
| Color | Silver | |
| Features | Tinel Lock | |
| Ingress Protection | Environment Resistant | |
| Includes | 4 pcs - 1 Backshell, 1 Braid, 1 O-Ring, 1 Tinel Ring | |
| Material Flammability Rating | - | |
| For Use With/Related Products | MIL-DTL-38999 Series III, IV | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TXR40AC45-1206AI | |
| Related Links | TXR40AC4, TXR40AC45-1206AI Datasheet, TE Connectivity Aerospace, Defense and Marine Distributor | |
