TE Connectivity AMP Connectors TXR54AB00-2010AI2J
- Mfg. Part Number
- TXR54AB00-2010AI2J
- Manufacturer
- TE Connectivity AMP Connectors
- Product Category
- Circular Connectors - Backshells and Cable Clamps
- Brief Description
- CONN BACKSHELL ADPT SZ20 37 OLIV
- Datasheet Download
- TXR54AB00-2010AI2J.pdf
Availability of TXR54AB00-2010AI2J
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 39.67520
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TXR54AB00-2010AI2J, we specialize in TE Connectivity AMP Connectors all series electronic components. TXR54AB00-2010AI2J can be shipped within 24 hours after order. If you have any demands for TXR54AB00-2010AI2J, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TXR54AB00-2010AI2J Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TXR54AB00-2010AI2J
| Internal Part Number | EIS-TXR54AB00-2010AI2J | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 100 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors - Backshells and Cable Clamps | |
| Series | TXR | |
| Type | Backshell, Heat Shrink Adapter | |
| Cable Opening | - | |
| Diameter - Outside | 1.343" (34.10mm) | |
| Shell Size - Insert | 20, 37 | |
| Thread Size | 1 3/16-18 UNEF | |
| Cable Exit | 180° | |
| Material | Aluminum Alloy | |
| Plating | Cadmium | |
| Shielding | Shielded | |
| Color | Olive Drab | |
| Features | Chain Attachment, Tinel Lock | |
| Ingress Protection | - | |
| Includes | 3 pcs - 1 Backshell, 1 Braid, 1 Tinel Ring | |
| Material Flammability Rating | - | |
| For Use With/Related Products | MIL-C-5015G MS3400 Series, MIL-C-81703 Series III, MIL-DTL-26482 Series II, MIL-DTL-83723 Series I, III | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TXR54AB00-2010AI2J | |
| Related Links | TXR54AB00, TXR54AB00-2010AI2J Datasheet, TE Connectivity AMP Connectors Distributor | |
