C&K Components U17L42D9AGE2
- Mfg. Part Number
- U17L42D9AGE2
- Manufacturer
- C&K Components
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE SPDT 5A 120V
- Datasheet Download
- U17L42D9AGE2.pdf
Availability of U17L42D9AGE2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 8.08520
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of U17L42D9AGE2, we specialize in C&K Components all series electronic components. U17L42D9AGE2 can be shipped within 24 hours after order. If you have any demands for U17L42D9AGE2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- U17L42D9AGE2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
U17L42D9AGE2
| Internal Part Number | EIS-U17L42D9AGE2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | 7000 | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Off-Mom | |
| Current Rating | 5A (AC/DC) | |
| Voltage Rating - AC | 120V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Flat Anti-Rotation | |
| Actuator Length | 21.29mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Through Hole, Right Angle | |
| Termination Style | PC Pin | |
| Panel Cutout Dimensions | - | |
| Bushing Thread | Unthreaded | |
| Ingress Protection | - | |
| Features | Black Actuator | |
| Actuator Material | Thermoplastic | |
| Electrical Life | 40,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | U17L42D9AGE2 | |
| Related Links | U17L42, U17L42D9AGE2 Datasheet, C&K Components Distributor | |
U17L42D9AGE2 Details Description
