C&K Components U21SCWZQE
- Mfg. Part Number
- U21SCWZQE
- Manufacturer
- C&K Components
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE DPDT 5A 120V
- Datasheet Download
- U21SCWZQE.pdf
Availability of U21SCWZQE
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.61500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of U21SCWZQE, we specialize in C&K Components all series electronic components. U21SCWZQE can be shipped within 24 hours after order. If you have any demands for U21SCWZQE, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- U21SCWZQE Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
U21SCWZQE
| Internal Part Number | EIS-U21SCWZQE | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | 7000 | |
| Packaging | Bulk | |
| Circuit | DPDT | |
| Switch Function | On-On | |
| Current Rating | 5A (AC/DC) | |
| Voltage Rating - AC | 120V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Standard Round | |
| Actuator Length | 10.67mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Panel Cutout Dimensions | Circular - 6.35mm Dia | |
| Bushing Thread | 1/4-40 | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Features | Epoxy Sealed Terminals | |
| Actuator Material | Brass, Chrome Plated | |
| Electrical Life | 100,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | U21SCWZQE | |
| Related Links | U21S, U21SCWZQE Datasheet, C&K Components Distributor | |
U21SCWZQE Details Description
