Allegro MicroSystems, LLC UDN2916B-T
- Mfg. Part Number
- UDN2916B-T
- Manufacturer
- Allegro MicroSystems, LLC
- Product Category
- PMIC - Motor Drivers, Controllers
- Brief Description
- IC MOTOR DRIVER PAR 24DIP
- Datasheet Download
- UDN2916B-T.pdf
Availability of UDN2916B-T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of UDN2916B-T, we specialize in Allegro MicroSystems, LLC all series electronic components. UDN2916B-T can be shipped within 24 hours after order. If you have any demands for UDN2916B-T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- UDN2916B-T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
UDN2916B-T
| Internal Part Number | EIS-UDN2916B-T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 15 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Motor Drivers, Controllers | |
| Series | - | |
| Motor Type - Stepper | Bipolar | |
| Motor Type - AC, DC | Brushed DC | |
| Function | Driver - Fully Integrated, Control and Power Stage | |
| Output Configuration | Half Bridge (4) | |
| Interface | Parallel | |
| Technology | Bipolar | |
| Step Resolution | - | |
| Applications | General Purpose | |
| Current - Output | 750mA | |
| Voltage - Supply | 4.75 V ~ 5.25 V | |
| Voltage - Load | 10 V ~ 45 V | |
| Operating Temperature | -20°C ~ 150°C (TJ) | |
| Mounting Type | Through Hole | |
| Package / Case | 24-PowerDIP (0.300", 7.62mm) | |
| Supplier Device Package | 24-DIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | UDN2916B-T | |
| Related Links | UDN29, UDN2916B-T Datasheet, Allegro MicroSystems, LLC Distributor | |
