Vishay Semiconductor/Diodes Division V10D120C-M3/I
- Mfg. Part Number
- V10D120C-M3/I
- Manufacturer
- Vishay Semiconductor/Diodes Division
- Product Category
- Diodes, Rectifiers - Arrays
- Brief Description
- DIODE ARRAY SCHOTTKY 120V SMPD
- Datasheet Download
- V10D120C-M3/I.pdf
Availability of V10D120C-M3/I
Available Quantity
7020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.72000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of V10D120C-M3/I, we specialize in Vishay Semiconductor/Diodes Division all series electronic components. V10D120C-M3/I can be shipped within 24 hours after order. If you have any demands for V10D120C-M3/I, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- V10D120C-M3/I Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
V10D120C-M3/I
| Internal Part Number | EIS-V10D120C-M3/I | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Trench MOS Barrier Schottky Rectifiers | |
| Video File | eSMP® Series: SlimSMA and SMPD Packages TMBS® Rectifiers in SMPD | |
| Featured Product | TMBS® Rectifiers in SMPD Package | |
| PCN Assembly/Origin | DD-009-2015-Rev-0 09/Mar/2015 | |
| Standard Package | 2,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Arrays | |
| Series | eSMP®, TMBS® | |
| Packaging | Tape & Reel (TR) | |
| Diode Configuration | 1 Pair Common Cathode | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 120V | |
| Current - Average Rectified (Io) (per Diode) | 5A | |
| Voltage - Forward (Vf) (Max) @ If | 940mV @ 5A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 500µA @ 120V | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab) Variant | |
| Supplier Device Package | SMPD | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | V10D120C-M3/I | |
| Related Links | V10D12, V10D120C-M3/I Datasheet, Vishay Semiconductor/Diodes Division Distributor | |
