Vicor Corporation V150A24C500BS
- Mfg. Part Number
- V150A24C500BS
- Manufacturer
- Vicor Corporation
- Product Category
- DC DC Converters
- Brief Description
- CONVERTER MOD DC/DC 24V 500W
- Datasheet Download
- V150A24C500BS.pdf
Availability of V150A24C500BS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 311.75000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of V150A24C500BS, we specialize in Vicor Corporation all series electronic components. V150A24C500BS can be shipped within 24 hours after order. If you have any demands for V150A24C500BS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- V150A24C500BS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
V150A24C500BS
| Internal Part Number | EIS-V150A24C500BS | |
| Lead Free Status / RoHS Status | Lead free / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | Maxi | |
| Packaging | Bulk | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 100V | |
| Voltage - Input (Max) | 200V | |
| Voltage - Output 1 | 24V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 20.83A | |
| Power (Watts) - Manufacture Series | 500W | |
| Voltage - Isolation | 3kV (3000V) | |
| Features | OVP, UVLO | |
| Mounting Type | Through Hole | |
| Package / Case | Full Brick | |
| Size / Dimension | 4.60" L x 2.20" W x 0.54" H (116.8mm x 55.9mm x 13.7mm) | |
| Operating Temperature | -20°C ~ 100°C | |
| Efficiency | 88.5% | |
| Power (Watts) - Max | 500W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | V150A24C500BS | |
| Related Links | V150A2, V150A24C500BS Datasheet, Vicor Corporation Distributor | |
