Vicor Corporation V150C5H100BL2
- Mfg. Part Number
- V150C5H100BL2
- Manufacturer
- Vicor Corporation
- Product Category
- DC DC Converters
- Brief Description
- CONVERTER MOD DC/DC 5V 100W
- Datasheet Download
- V150C5H100BL2.pdf
Availability of V150C5H100BL2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 230.55000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of V150C5H100BL2, we specialize in Vicor Corporation all series electronic components. V150C5H100BL2 can be shipped within 24 hours after order. If you have any demands for V150C5H100BL2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- V150C5H100BL2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
V150C5H100BL2
| Internal Part Number | EIS-V150C5H100BL2 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Maxi/Mini/Micro Design Guide, Appl Manual | |
| Standard Package | 1 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | MICRO | |
| Packaging | Bulk | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 100V | |
| Voltage - Input (Max) | 200V | |
| Voltage - Output 1 | 5V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 20A | |
| Power (Watts) - Manufacture Series | 100W | |
| Voltage - Isolation | 3kV (3000V) | |
| Features | OVP, UVLO | |
| Mounting Type | Through Hole | |
| Package / Case | Quarter Brick | |
| Size / Dimension | 2.28" L x 1.45" W x 0.65" H (57.9mm x 36.8mm x 16.5mm) | |
| Operating Temperature | -40°C ~ 100°C | |
| Efficiency | 82.7% | |
| Power (Watts) - Max | 100W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | V150C5H100BL2 | |
| Related Links | V150C5, V150C5H100BL2 Datasheet, Vicor Corporation Distributor | |
V150C5H100BL2 Details Description
