Vicor Corporation V48C5E100B
- Mfg. Part Number
- V48C5E100B
- Manufacturer
- Vicor Corporation
- Product Category
- DC DC Converters
- Brief Description
- CONVERTER MOD DC/DC 5V 100W
- Datasheet Download
- V48C5E100B.pdf
Availability of V48C5E100B
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 105.85000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of V48C5E100B, we specialize in Vicor Corporation all series electronic components. V48C5E100B can be shipped within 24 hours after order. If you have any demands for V48C5E100B, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- V48C5E100B Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
V48C5E100B
| Internal Part Number | EIS-V48C5E100B | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Maxi/Mini/Micro Design Guide, Appl Manual | |
| Standard Package | 1 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | MICRO | |
| Packaging | Bulk | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 36V | |
| Voltage - Input (Max) | 75V | |
| Voltage - Output 1 | 5V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 20A | |
| Power (Watts) - Manufacture Series | 100W | |
| Voltage - Isolation | 3kV (3000V) | |
| Features | OVP, UVLO | |
| Mounting Type | Through Hole | |
| Package / Case | Quarter Brick | |
| Size / Dimension | 2.28" L x 1.45" W x 0.54" H (57.9mm x 36.8mm x 13.7mm) | |
| Operating Temperature | -10°C ~ 100°C | |
| Efficiency | 85% | |
| Power (Watts) - Max | 100W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | V48C5E100B | |
| Related Links | V48C5, V48C5E100B Datasheet, Vicor Corporation Distributor | |
