Vishay Semiconductor/Diodes Division V8PAL45-M3/I
- Mfg. Part Number
- V8PAL45-M3/I
- Manufacturer
- Vishay Semiconductor/Diodes Division
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE SCHOTTKY 45V 4A DO221BC
- Datasheet Download
- V8PAL45-M3/I.pdf
Availability of V8PAL45-M3/I
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.28964
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of V8PAL45-M3/I, we specialize in Vishay Semiconductor/Diodes Division all series electronic components. V8PAL45-M3/I can be shipped within 24 hours after order. If you have any demands for V8PAL45-M3/I, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- V8PAL45-M3/I Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
V8PAL45-M3/I
| Internal Part Number | EIS-V8PAL45-M3/I | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Wafer Material Update 30/Jun/2015 | |
| Standard Package | 14,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | Automotive, AEC-Q101 | |
| Packaging | Tape & Reel (TR) | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 45V | |
| Current - Average Rectified (Io) | 4A (DC) | |
| Voltage - Forward (Vf) (Max) @ If | 570mV @ 8A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 1.85mA @ 45V | |
| Capacitance @ Vr, F | - | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-221BC, SMA Flat Leads Exposed Pad | |
| Supplier Device Package | DO-221BC (SMPA) | |
| Operating Temperature - Junction | -40°C ~ 150°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | V8PAL45-M3/I | |
| Related Links | V8PAL4, V8PAL45-M3/I Datasheet, Vishay Semiconductor/Diodes Division Distributor | |
V8PAL45-M3/I Details Description
