ST VB027SP-E
- Mfg. Part Number
- VB027SP-E
- Manufacturer
- ST
- Product Category
- PMIC - Power Distribution Switches, Load Drivers
- Brief Description
- IC COIL DRIVER PAR 10POWERSO
- Datasheet Download
- VB027SP-E.pdf
Availability of VB027SP-E
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VB027SP-E, we specialize in ST all series electronic components. VB027SP-E can be shipped within 24 hours after order. If you have any demands for VB027SP-E, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VB027SP-E Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VB027SP-E
| Internal Part Number | EIS-VB027SP-E | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | VB027SP-E View All Specifications | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Series | VIPower™ | |
| Packaging | Tube | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | Low Side | |
| Output Type | Bipolar | |
| Interface | Parallel | |
| Voltage - Load | 4.5 V ~ 5.5 V | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 8A | |
| Rds On (Typ) | - | |
| Input Type | Non-Inverting | |
| Features | Status Flag | |
| Fault Protection | Over Temperature | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Package / Case | PowerSO-10 Exposed Bottom Pad | |
| Supplier Device Package | 10-PowerSO | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VB027SP-E | |
| Related Links | VB02, VB027SP-E Datasheet, ST Distributor | |
VB027SP-E Details Description
