Vicor Corporation VE-2WR-CW-S
- Mfg. Part Number
- VE-2WR-CW-S
- Manufacturer
- Vicor Corporation
- Product Category
- DC DC Converters
- Brief Description
- CONVERTER MOD DC/DC 7.5V 100W
- Datasheet Download
- VE-2WR-CW-S.pdf
Availability of VE-2WR-CW-S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 227.65000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VE-2WR-CW-S, we specialize in Vicor Corporation all series electronic components. VE-2WR-CW-S can be shipped within 24 hours after order. If you have any demands for VE-2WR-CW-S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VE-2WR-CW-S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VE-2WR-CW-S
| Internal Part Number | EIS-VE-2WR-CW-S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | VI-200, VI-J00 Design Guide, Appl Manual | |
| Standard Package | 1 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | VE-200 | |
| Packaging | Bulk | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 18V | |
| Voltage - Input (Max) | 36V | |
| Voltage - Output 1 | 7.5V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 13.33A | |
| Power (Watts) - Manufacture Series | 100W | |
| Voltage - Isolation | 3kV (3000V) | |
| Features | OCP, OTP, OVP, SCP | |
| Mounting Type | Through Hole | |
| Package / Case | Full Brick | |
| Size / Dimension | 4.60" L x 1.80" W x 0.52" H (116.8mm x 45.7mm x 13.2mm) | |
| Operating Temperature | -25°C ~ 85°C | |
| Efficiency | 90% | |
| Power (Watts) - Max | 100W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VE-2WR-CW-S | |
| Related Links | VE-2W, VE-2WR-CW-S Datasheet, Vicor Corporation Distributor | |
VE-2WR-CW-S Details Description
