CUI Inc. VESD2-S5-D12-SIP
- Mfg. Part Number
- VESD2-S5-D12-SIP
- Manufacturer
- CUI Inc.
- Product Category
- DC DC Converters
- Brief Description
- CONVERTER DC/DC 2W +/-12V 83MA
- Datasheet Download
- VESD2-S5-D12-SIP.pdf
Availability of VESD2-S5-D12-SIP
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VESD2-S5-D12-SIP, we specialize in CUI Inc. all series electronic components. VESD2-S5-D12-SIP can be shipped within 24 hours after order. If you have any demands for VESD2-S5-D12-SIP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VESD2-S5-D12-SIP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VESD2-S5-D12-SIP
| Internal Part Number | EIS-VESD2-S5-D12-SIP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | VESD2-SIP Cert of Compliance | |
| PCN Obsolescence/ EOL | Multiple Series 31/Jul/2013 | |
| Standard Package | 25 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | VESD2-SIP | |
| Packaging | Tube | |
| Type | Isolated Module | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 5.5V | |
| Voltage - Output 1 | 12V | |
| Voltage - Output 2 | -12V | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 83mA, 83mA | |
| Power (Watts) - Manufacture Series | 2W | |
| Voltage - Isolation | 3kV (3000V) | |
| Features | SCP | |
| Mounting Type | Through Hole | |
| Package / Case | 7-SIP Module (5 Leads) | |
| Size / Dimension | 0.77" L x 0.28" W x 0.39" H (19.6mm x 7.0mm x 10.0mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 85% | |
| Power (Watts) - Max | 2W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VESD2-S5-D12-SIP | |
| Related Links | VESD2-S5, VESD2-S5-D12-SIP Datasheet, CUI Inc. Distributor | |
VESD2-S5-D12-SIP Details Description
