TDK Corporation VLS201610CX-R47M
- Mfg. Part Number
- VLS201610CX-R47M
- Manufacturer
- TDK Corporation
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 470NH 2.69A 50 MOHM
- Datasheet Download
- VLS201610CX-R47M.pdf
Availability of VLS201610CX-R47M
Available Quantity
7020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.12054
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VLS201610CX-R47M, we specialize in TDK Corporation all series electronic components. VLS201610CX-R47M can be shipped within 24 hours after order. If you have any demands for VLS201610CX-R47M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VLS201610CX-R47M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VLS201610CX-R47M
| Internal Part Number | EIS-VLS201610CX-R47M | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | VLS-CX | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 470nH | |
| Tolerance | ±20% | |
| Current Rating | 2.69A | |
| Current - Saturation | 3.15A | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 50 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -40°C ~ 105°C | |
| Frequency - Test | 1MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.079" L x 0.063" W (2.00mm x 1.60mm) | |
| Height - Seated (Max) | 0.039" (1.00mm) | |
| Supplier Device Package | 2016 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VLS201610CX-R47M | |
| Related Links | VLS20161, VLS201610CX-R47M Datasheet, TDK Corporation Distributor | |
VLS201610CX-R47M Details Description
