ST VN610SP-E
- Mfg. Part Number
- VN610SP-E
- Manufacturer
- ST
- Product Category
- PMIC - Power Distribution Switches, Load Drivers
- Brief Description
- RELAY SSR HI-SIDE 1CH POWERSO10
- Datasheet Download
- VN610SP-E.pdf
Availability of VN610SP-E
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.51440
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VN610SP-E, we specialize in ST all series electronic components. VN610SP-E can be shipped within 24 hours after order. If you have any demands for VN610SP-E, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VN610SP-E Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VN610SP-E
| Internal Part Number | EIS-VN610SP-E | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | VN610SP-E View All Specifications | |
| Product Training Modules | VIPower H-Bridges | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Series | VIPower™ | |
| Packaging | Tube | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | High Side | |
| Output Type | N-Channel | |
| Interface | On/Off | |
| Voltage - Load | 5.5 V ~ 36 V | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 45A | |
| Rds On (Typ) | 10 mOhm (Max) | |
| Input Type | Non-Inverting | |
| Features | Auto Restart | |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Over Voltage | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Package / Case | PowerSO-10 Exposed Bottom Pad | |
| Supplier Device Package | 10-PowerSO | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VN610SP-E | |
| Related Links | VN61, VN610SP-E Datasheet, ST Distributor | |
VN610SP-E Details Description
