ST VNQ5E160KTR-E
- Mfg. Part Number
- VNQ5E160KTR-E
- Manufacturer
- ST
- Product Category
- PMIC - Power Distribution Switches, Load Drivers
- Brief Description
- IC SW M0-5 4CH 10A DGTL PWRSSO24
- Datasheet Download
- VNQ5E160KTR-E.pdf
Availability of VNQ5E160KTR-E
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.71600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VNQ5E160KTR-E, we specialize in ST all series electronic components. VNQ5E160KTR-E can be shipped within 24 hours after order. If you have any demands for VNQ5E160KTR-E, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VNQ5E160KTR-E Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VNQ5E160KTR-E
| Internal Part Number | EIS-VNQ5E160KTR-E | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | VNQ5E160K-E View All Specifications | |
| Product Training Modules | VIPower™ M0-5:Smart Power for High Side Switches and Solid State Relays VIPower H-Bridges | |
| Standard Package | 1,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Series | VIPower™ | |
| Packaging | Tape & Reel (TR) | |
| Switch Type | General Purpose | |
| Number of Outputs | 4 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | High Side | |
| Output Type | N-Channel | |
| Interface | On/Off | |
| Voltage - Load | 4.5 V ~ 28 V | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 7A | |
| Rds On (Typ) | 160 mOhm (Max) | |
| Input Type | Non-Inverting | |
| Features | Auto Restart | |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Package / Case | 24-SOP (0.295", 7.50mm Width) Exposed Pad | |
| Supplier Device Package | PowerSSO-24™ | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VNQ5E160KTR-E | |
| Related Links | VNQ5E1, VNQ5E160KTR-E Datasheet, ST Distributor | |
VNQ5E160KTR-E Details Description
