Vishay Semiconductor/Diodes Division VS-12CWQ06FNHM3
,-SC-63.jpg)
- Mfg. Part Number
- VS-12CWQ06FNHM3
- Manufacturer
- Vishay Semiconductor/Diodes Division
- Product Category
- Diodes, Rectifiers - Arrays
- Brief Description
- DIODE ARRAY SCHOTTKY 60V 6A DPAK
- Datasheet Download
- VS-12CWQ06FNHM3.pdf
Availability of VS-12CWQ06FNHM3
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.08216
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of VS-12CWQ06FNHM3, we specialize in Vishay Semiconductor/Diodes Division all series electronic components. VS-12CWQ06FNHM3 can be shipped within 24 hours after order. If you have any demands for VS-12CWQ06FNHM3, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- VS-12CWQ06FNHM3 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
VS-12CWQ06FNHM3
| Internal Part Number | EIS-VS-12CWQ06FNHM3 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 75 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Arrays | |
| Series | Automotive, AEC-Q101 | |
| Packaging | Tube | |
| Diode Configuration | 1 Pair Common Cathode | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 60V | |
| Current - Average Rectified (Io) (per Diode) | 6A | |
| Voltage - Forward (Vf) (Max) @ If | 790mV @ 12A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 3mA @ 60V | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 | |
| Supplier Device Package | D-PAK (TO-252AA) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | VS-12CWQ06FNHM3 | |
| Related Links | VS-12CW, VS-12CWQ06FNHM3 Datasheet, Vishay Semiconductor/Diodes Division Distributor | |
