Stackpole Electronics Inc. WW3FT120R
- Mfg. Part Number
- WW3FT120R
- Manufacturer
- Stackpole Electronics Inc.
- Product Category
- Through Hole Resistors
- Brief Description
- RES 120 OHM 3W 1% AXIAL
- Datasheet Download
- WW3FT120R.pdf
Availability of WW3FT120R
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.21780
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of WW3FT120R, we specialize in Stackpole Electronics Inc. all series electronic components. WW3FT120R can be shipped within 24 hours after order. If you have any demands for WW3FT120R, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- WW3FT120R Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
WW3FT120R
| Internal Part Number | EIS-WW3FT120R | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Pulse Handling Resistor Solutions | |
| RoHS Information | RoHS Compliance | |
| Featured Product | WW Series Resistors | |
| PCN Part Number | Global Part Number 9/Aug/2010 | |
| Standard Package | 2,000 | |
| Category | Resistors | |
| Family | Through Hole Resistors | |
| Series | WW | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 120 | |
| Tolerance | ±1% | |
| Power (Watts) | 3W | |
| Composition | Wirewound | |
| Features | Moisture Resistant | |
| Temperature Coefficient | ±20ppm/°C | |
| Operating Temperature | -55°C ~ 350°C | |
| Package / Case | Axial | |
| Supplier Device Package | Axial | |
| Size / Dimension | 0.187" Dia x 0.560" L (4.75mm x 14.22mm) | |
| Height | - | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | WW3FT120R | |
| Related Links | WW3F, WW3FT120R Datasheet, Stackpole Electronics Inc. Distributor | |
WW3FT120R Details Description
