Zilog Z8F6422AR020EC00TR
- Mfg. Part Number
- Z8F6422AR020EC00TR
- Manufacturer
- Zilog
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC ENCORE MCU FLASH 64K 64LQFP
- Datasheet Download
- Z8F6422AR020EC00TR.pdf
Availability of Z8F6422AR020EC00TR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of Z8F6422AR020EC00TR, we specialize in Zilog all series electronic components. Z8F6422AR020EC00TR can be shipped within 24 hours after order. If you have any demands for Z8F6422AR020EC00TR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- Z8F6422AR020EC00TR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
Z8F6422AR020EC00TR
| Internal Part Number | EIS-Z8F6422AR020EC00TR | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Standard Package | 1,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | Encore!® XP® | |
| Packaging | Tape & Reel (TR) | |
| Core Processor | eZ8 | |
| Core Size | 8-Bit | |
| Speed | 20MHz | |
| Connectivity | I²C, IrDA, SPI, UART/USART | |
| Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, WDT | |
| Number of I/O | 46 | |
| Program Memory Size | 64KB (64K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 4K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 3 V ~ 3.6 V | |
| Data Converters | A/D 12x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 105°C | |
| Package / Case | 64-LQFP | |
| Supplier Device Package | * | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | Z8F6422AR020EC00TR | |
| Related Links | Z8F6422AR, Z8F6422AR020EC00TR Datasheet, Zilog Distributor | |
Z8F6422AR020EC00TR Details Description
