Omron Automation & Safety ZC-Q2155-MD VCT 1M
- Mfg. Part Number
- ZC-Q2155-MD VCT 1M
- Manufacturer
- Omron Automation & Safety
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SWITCH CROSS ROLL PLNGR SPDT 10A
- Datasheet Download
- ZC-Q2155-MD VCT 1M.pdf
Availability of ZC-Q2155-MD VCT 1M
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 200.46000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ZC-Q2155-MD VCT 1M, we specialize in Omron Automation & Safety all series electronic components. ZC-Q2155-MD VCT 1M can be shipped within 24 hours after order. If you have any demands for ZC-Q2155-MD VCT 1M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ZC-Q2155-MD VCT 1M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ZC-Q2155-MD VCT 1M
| Internal Part Number | EIS-ZC-Q2155-MD VCT 1M | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | ZC | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 10A (AC), 6A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Roller Plunger | |
| Mounting Type | Panel Mount | |
| Termination Style | Cable Leads | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Features | Cable Length 1m | |
| Operating Force, Torque | 1200gf | |
| Release Force | 500gf | |
| Pretravel | 0.060" (1.5mm) | |
| Differential Travel | 0.008" (0.2mm) | |
| Overtravel | 0.118" (3.0mm) | |
| Operating Position | 1.866" (47.4mm) | |
| Mechanical Life | 10,000,000 Cycles | |
| Electrical Life | 500,000 Cycles | |
| Operating Temperature | -10°C ~ 80°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ZC-Q2155-MD VCT 1M | |
| Related Links | ZC-Q2155-, ZC-Q2155-MD VCT 1M Datasheet, Omron Automation & Safety Distributor | |
ZC-Q2155-MD VCT 1M Details Description
