Zilog ZGP323HAH2808C
- Mfg. Part Number
- ZGP323HAH2808C
- Manufacturer
- Zilog
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC Z8 GP MCU 8K OTP 28SSOP
- Datasheet Download
- ZGP323HAH2808C.pdf
Availability of ZGP323HAH2808C
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ZGP323HAH2808C, we specialize in Zilog all series electronic components. ZGP323HAH2808C can be shipped within 24 hours after order. If you have any demands for ZGP323HAH2808C, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ZGP323HAH2808C Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ZGP323HAH2808C
| Internal Part Number | EIS-ZGP323HAH2808C | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Standard Package | 47 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | Z8® GP™ | |
| Packaging | Tube | |
| Core Processor | Z8 | |
| Core Size | 8-Bit | |
| Speed | 8MHz | |
| Connectivity | - | |
| Peripherals | HLVD, POR, WDT | |
| Number of I/O | 24 | |
| Program Memory Size | 8KB (8K x 8) | |
| Program Memory Type | OTP | |
| EEPROM Size | - | |
| RAM Size | 237 x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2 V ~ 5.5 V | |
| Data Converters | - | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 28-SSOP (0.209", 5.30mm Width) | |
| Supplier Device Package | * | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ZGP323HAH2808C | |
| Related Links | ZGP323H, ZGP323HAH2808C Datasheet, Zilog Distributor | |
ZGP323HAH2808C Details Description
