Diodes Incorporated ZMM5233B-7
- Mfg. Part Number
- ZMM5233B-7
- Manufacturer
- Diodes Incorporated
- Product Category
- Diodes - Zener - Single
- Brief Description
- DIODE ZENER 6V 500MW MINIMELF
- Datasheet Download
- ZMM5233B-7.pdf
Availability of ZMM5233B-7
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ZMM5233B-7, we specialize in Diodes Incorporated all series electronic components. ZMM5233B-7 can be shipped within 24 hours after order. If you have any demands for ZMM5233B-7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ZMM5233B-7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ZMM5233B-7
| Internal Part Number | EIS-ZMM5233B-7 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS Cert of Compliance | |
| Other Drawings | MiniMELF (DL-35) 500mW Top | |
| PCN Obsolescence/ EOL | Select Discrete Devices 20/Feb/2014 | |
| Standard Package | 1 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Series | - | |
| Packaging | Cut Tape (CT) | |
| Voltage - Zener (Nom) (Vz) | 6V | |
| Tolerance | ±5% | |
| Power - Max | 500mW | |
| Impedance (Max) (Zzt) | 7 Ohm | |
| Current - Reverse Leakage @ Vr | 5µA @ 3.5V | |
| Voltage - Forward (Vf) (Max) @ If | 1.5V @ 200mA | |
| Operating Temperature | -65°C ~ 175°C | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-213AC, MINI-MELF, SOD-80 | |
| Supplier Device Package | Mini MELF | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ZMM5233B-7 | |
| Related Links | ZMM52, ZMM5233B-7 Datasheet, Diodes Incorporated Distributor | |
ZMM5233B-7 Details Description
