TDK-Lambda Americas, Inc. ZPD40524
- Mfg. Part Number
- ZPD40524
- Manufacturer
- TDK-Lambda Americas, Inc.
- Product Category
- AC DC Converters
- Brief Description
- AC/DC CONVERTER 5V 24V 40W
- Datasheet Download
- ZPD40524.pdf
Availability of ZPD40524
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 52.06000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ZPD40524, we specialize in TDK-Lambda Americas, Inc. all series electronic components. ZPD40524 can be shipped within 24 hours after order. If you have any demands for ZPD40524, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ZPD40524 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ZPD40524
| Internal Part Number | EIS-ZPD40524 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Converters | |
| Series | ZP40 | |
| Type | Open Frame | |
| Number of Outputs | 2 | |
| Voltage - Input | 90 ~ 264 VAC | |
| Voltage - Output 1 | 5V | |
| Voltage - Output 2 | 24V | |
| Voltage - Output 3 | - | |
| Voltage - Output 4 | - | |
| Current - Output (Max) | 3.2A, 1A | |
| Power (Watts) | 40W | |
| Applications | ITE (Commercial) | |
| Voltage - Isolation | 3kV (3000V) | |
| Efficiency | 78% | |
| Operating Temperature | 0°C ~ 70°C (With Derating) | |
| Features | Adjustable Output, DC Input Capable | |
| Mounting Type | Chassis Mount | |
| Size / Dimension | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | |
| Minimum Load Required | No | |
| Approvals | CE | |
| Power (Watts) - Max | 40W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ZPD40524 | |
| Related Links | ZPD4, ZPD40524 Datasheet, TDK-Lambda Americas, Inc. Distributor | |
