TDK-Lambda Americas, Inc. ZWS100AF3
- Mfg. Part Number
- ZWS100AF3
- Manufacturer
- TDK-Lambda Americas, Inc.
- Product Category
- AC DC Converters
- Brief Description
- AC/DC CONVERTER 3.3V 100W
- Datasheet Download
- ZWS100AF3.pdf
Availability of ZWS100AF3
Available Quantity
5023 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 84.69000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ZWS100AF3, we specialize in TDK-Lambda Americas, Inc. all series electronic components. ZWS100AF3 can be shipped within 24 hours after order. If you have any demands for ZWS100AF3, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ZWS100AF3 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ZWS100AF3
| Internal Part Number | EIS-ZWS100AF3 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Converters | |
| Series | ZWS-AF | |
| Type | Open Frame | |
| Number of Outputs | 1 | |
| Voltage - Input | 85 ~ 265 VAC | |
| Voltage - Output 1 | 3.3V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Voltage - Output 4 | - | |
| Current - Output (Max) | 20A | |
| Power (Watts) | 100W | |
| Applications | ITE (Commercial) | |
| Voltage - Isolation | 3kV (3000V) | |
| Efficiency | 69% | |
| Operating Temperature | -10°C ~ 70°C (With Derating) | |
| Features | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | |
| Mounting Type | Chassis Mount | |
| Size / Dimension | 8.74" L x 2.44" W x 1.38" H (222.0mm x 62.0mm x 35.0mm) | |
| Minimum Load Required | - | |
| Approvals | CE | |
| Power (Watts) - Max | 66W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ZWS100AF3 | |
| Related Links | ZWS1, ZWS100AF3 Datasheet, TDK-Lambda Americas, Inc. Distributor | |
