TDK-Lambda Americas, Inc. ZWS300BAF12
- Mfg. Part Number
- ZWS300BAF12
- Manufacturer
- TDK-Lambda Americas, Inc.
- Product Category
- AC DC Converters
- Brief Description
- AC/DC CONVERTER 12V 300W
- Datasheet Download
- ZWS300BAF12.pdf
Availability of ZWS300BAF12
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 189.88000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ZWS300BAF12, we specialize in TDK-Lambda Americas, Inc. all series electronic components. ZWS300BAF12 can be shipped within 24 hours after order. If you have any demands for ZWS300BAF12, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ZWS300BAF12 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ZWS300BAF12
| Internal Part Number | EIS-ZWS300BAF12 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | ZWS300BAF.igsZWS300BAF.stp | |
| Standard Package | 1 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Converters | |
| Series | ZWS300BAF | |
| Type | Open Frame | |
| Number of Outputs | 1 | |
| Voltage - Input | 85 ~ 265 VAC | |
| Voltage - Output 1 | 12V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Voltage - Output 4 | - | |
| Current - Output (Max) | 25A | |
| Power (Watts) | 300W (336W Forced Air) | |
| Applications | ITE (Commercial) | |
| Voltage - Isolation | 3kV (3000V) | |
| Efficiency | 89% | |
| Operating Temperature | -10°C ~ 70°C (With Derating) | |
| Features | Adjustable Output, DC Input Capable, PFC, Universal Input | |
| Mounting Type | Chassis Mount | |
| Size / Dimension | 7.09" L x 3.31" W x 1.65" H (180.0mm x 84.0mm x 42.0mm) | |
| Minimum Load Required | No | |
| Approvals | CE, cURus, TUV | |
| Power (Watts) - Max | 300W (336W Forced Air) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ZWS300BAF12 | |
| Related Links | ZWS30, ZWS300BAF12 Datasheet, TDK-Lambda Americas, Inc. Distributor | |
ZWS300BAF12 Details Description
