TDK-Lambda Americas, Inc. ZWS75AF12
- Mfg. Part Number
- ZWS75AF12
- Manufacturer
- TDK-Lambda Americas, Inc.
- Product Category
- AC DC Converters
- Brief Description
- AC/DC CONVERTER 12V 75W
- Datasheet Download
- ZWS75AF12.pdf
Availability of ZWS75AF12
Available Quantity
5037 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 73.81000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ZWS75AF12, we specialize in TDK-Lambda Americas, Inc. all series electronic components. ZWS75AF12 can be shipped within 24 hours after order. If you have any demands for ZWS75AF12, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ZWS75AF12 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ZWS75AF12
| Internal Part Number | EIS-ZWS75AF12 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Converters | |
| Series | ZWS | |
| Type | Open Frame | |
| Number of Outputs | 1 | |
| Voltage - Input | 85 ~ 265 VAC | |
| Voltage - Output 1 | 12V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Voltage - Output 4 | - | |
| Current - Output (Max) | 6.3A | |
| Power (Watts) | 75W | |
| Applications | ITE (Commercial) | |
| Voltage - Isolation | 3kV (3000V) | |
| Efficiency | 78% | |
| Operating Temperature | -10°C ~ 60°C (With Derating) | |
| Features | Adjustable Output, DC Input Capable, PFC, Universal Input | |
| Mounting Type | Chassis Mount | |
| Size / Dimension | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) | |
| Minimum Load Required | - | |
| Approvals | CE | |
| Power (Watts) - Max | 75W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ZWS75AF12 | |
| Related Links | ZWS7, ZWS75AF12 Datasheet, TDK-Lambda Americas, Inc. Distributor | |
ZWS75AF12 Details Description
