Diodes Incorporated ZXMS6004N8-13
- Mfg. Part Number
- ZXMS6004N8-13
- Manufacturer
- Diodes Incorporated
- Product Category
- PMIC - Power Distribution Switches, Load Drivers
- Brief Description
- MOSFET N-CH 60V 1.3A S08
- Datasheet Download
- ZXMS6004N8-13.pdf
Availability of ZXMS6004N8-13
Available Quantity
7520 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.21960
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ZXMS6004N8-13, we specialize in Diodes Incorporated all series electronic components. ZXMS6004N8-13 can be shipped within 24 hours after order. If you have any demands for ZXMS6004N8-13, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ZXMS6004N8-13 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ZXMS6004N8-13
| Internal Part Number | EIS-ZXMS6004N8-13 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Series | INTELLIFET® | |
| Packaging | Tape & Reel (TR) | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | Low Side | |
| Output Type | N-Channel | |
| Interface | On/Off | |
| Voltage - Load | 60V (Max) | |
| Voltage - Supply (Vcc/Vdd) | 3.3V, 5V | |
| Current - Output (Max) | 1.3A | |
| Rds On (Typ) | 350 mOhm | |
| Input Type | Non-Inverting | |
| Features | Auto Restart | |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Over Voltage | |
| Operating Temperature | -40°C ~ 125°C (TA) | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SO | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ZXMS6004N8-13 | |
| Related Links | ZXMS60, ZXMS6004N8-13 Datasheet, Diodes Incorporated Distributor | |
