Molex Connector Corporation 0009016191
- Mfg. Part Number
- 0009016191
- Manufacturer
- Molex Connector Corporation
- Product Category
- Card Edge Connectors - Housings
- Brief Description
- CONN CARDEDGE HSG 19POS 0.156"
- Datasheet Download
- 0009016191.pdf
Availability of 0009016191
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0009016191, we specialize in Molex Connector Corporation all series electronic components. 0009016191 can be shipped within 24 hours after order. If you have any demands for 0009016191, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0009016191 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0009016191
| Internal Part Number | EIS-0009016191 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 0009016191 Cert of Compliance | |
| 3D Model | 09-01-6191.stp | |
| PCN Obsolescence/ EOL | 2574/6422/172159 Series 17/Sep/2014 | |
| PCN Design/Specification | V2 6/6 Nylon Resin Additional Supplier 05/Nov/2014 | |
| Standard Package | 250 | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Housings | |
| Series | KK® 2574 | |
| Packaging | Bulk | |
| Card Type | Non Specified - Single Edge | |
| Number of Positions | 19 | |
| Card Thickness | 0.062" (1.57mm) | |
| Pitch | 0.156" (3.96mm) | |
| Features | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Color | Natural | |
| Flange Feature | - | |
| Material - Insulation | Polyamide (PA66), Nylon 6/6 | |
| Note | Contacts Not Provided | |
| Material Flammability Rating | UL94 V-2 | |
| Operating Temperature | 0°C ~ 75°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0009016191 | |
| Related Links | 00090, 0009016191 Datasheet, Molex Connector Corporation Distributor | |
