Molex Connector Corporation 0022152235
- Mfg. Part Number
- 0022152235
- Manufacturer
- Molex Connector Corporation
- Product Category
- Rectangular Connectors - Headers, Receptacles, Female Sockets
- Brief Description
- Connector Receptacle 23 Position 0.100" (2.54mm) Tin Through Hole, Right Angle
- Datasheet Download
- 0022152235.pdf
Availability of 0022152235
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.65912
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0022152235, we specialize in Molex Connector Corporation all series electronic components. 0022152235 can be shipped within 24 hours after order. If you have any demands for 0022152235, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0022152235 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0022152235
| Internal Part Number | EIS-0022152235 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 810 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Receptacles, Female Sockets | |
| Series | KK® 4455 | |
| Packaging | Tray | |
| Connector Type | Receptacle | |
| Contact Type | Female Socket | |
| Number of Positions | 23 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | - | |
| Contact Finish | Tin | |
| Contact Finish Thickness | 100µin (2.54µm) | |
| Color | White | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0022152235 | |
| Related Links | 00221, 0022152235 Datasheet, Molex Connector Corporation Distributor | |
