Schurter 0031.8420
- Mfg. Part Number
- 0031.8420
- Manufacturer
- Schurter
- Product Category
- Fuses
- Brief Description
- FUSE GLASS 2.5A 250VAC 5X20MM
- Datasheet Download
- 0031.8420.pdf
Availability of 0031.8420
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.83300
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0031.8420, we specialize in Schurter all series electronic components. 0031.8420 can be shipped within 24 hours after order. If you have any demands for 0031.8420, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0031.8420 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0031.8420
| Internal Part Number | EIS-0031.8420 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | 0031.yyyy OGN/OGN-SMD 02/Jul/2013 0031.8yyy Material 01/Sep/2014 | |
| Standard Package | 400 | |
| Category | Circuit Protection | |
| Family | Fuses | |
| Series | OGN-SMD | |
| Packaging | Tape & Reel (TR) | |
| Fuse Type | Cartridge, Glass | |
| Current Rating | 2.5A | |
| Voltage Rating - AC | 250V | |
| Voltage Rating - DC | - | |
| Response Time | Fast | |
| Package / Case | 5mm x 20mm w/Holder | |
| Mounting Type | Holder/Surface Mount | |
| Breaking Capacity @ Rated Voltage | 35A | |
| Melting I²t | 9.19 | |
| Approvals | cULus, VDE | |
| Operating Temperature | -40°C ~ 85°C | |
| Color | - | |
| Size / Dimension | 0.197" Dia x 0.787" L (5.00mm x 20.00mm) | |
| DC Cold Resistance | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0031.8420 | |
| Related Links | 0031, 0031.8420 Datasheet, Schurter Distributor | |
