Molex Connector Corporation 0191270086
- Mfg. Part Number
- 0191270086
- Manufacturer
- Molex Connector Corporation
- Product Category
- Terminals - Spade Connectors
- Brief Description
- CONN FLANGED SPADE #8 10-12AWG
- Datasheet Download
- 0191270086.pdf
Availability of 0191270086
Available Quantity
6504 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.24450
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 0191270086, we specialize in Molex Connector Corporation all series electronic components. 0191270086 can be shipped within 24 hours after order. If you have any demands for 0191270086, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 0191270086 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
0191270086
| Internal Part Number | EIS-0191270086 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 19127-0086-C Cert of Compliance | |
| Standard Package | 100 | |
| Category | Connectors, Interconnects | |
| Family | Terminals - Spade Connectors | |
| Series | Avikrimp™ | |
| Packaging | Bulk | |
| Terminal Type | Flanged | |
| Stud/Tab Size | 8 Stud | |
| Width - Outer Edges | 0.385" (9.78mm) | |
| Length - Overall | 1.026" (26.06mm) | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Crimp | |
| Wire Gauge | 10-12 AWG | |
| Insulation | Insulated | |
| Features | - | |
| Color | Yellow | |
| Contact Finish | Electro-Tin | |
| Contact Material | Copper | |
| Insulation Diameter | 0.225" (5.72mm) | |
| Material - Insulation | Polyamide (PA), Nylon | |
| Length - Ring Center to Termination | 0.270" (6.86mm) | |
| Length - Termination | 0.400" (10.16mm) | |
| Tongue Inside Opening | 0.173" (4.39mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 0191270086 | |
| Related Links | 01912, 0191270086 Datasheet, Molex Connector Corporation Distributor | |
0191270086 Details Description
