TE Connectivity Aerospace, Defense and Marine 1045520-1
- Mfg. Part Number
- 1045520-1
- Manufacturer
- TE Connectivity Aerospace, Defense and Marine
- Product Category
- Coaxial Connectors (RF)
- Brief Description
- CONN SSMA PLUG R/A 50 OHM SOLDER
- Datasheet Download
- 1045520-1.pdf
Availability of 1045520-1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 47.14850
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1045520-1, we specialize in TE Connectivity Aerospace, Defense and Marine all series electronic components. 1045520-1 can be shipped within 24 hours after order. If you have any demands for 1045520-1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1045520-1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1045520-1
| Internal Part Number | EIS-1045520-1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 1045520-1 Statement of ComplianceRoHS 2 Statement | |
| Featured Product | SMA Connectors | |
| 3D Model | 1045520-1.pdf | |
| Standard Package | 400 | |
| Category | Connectors, Interconnects | |
| Family | Coaxial Connectors (RF) | |
| Series | - | |
| Packaging | Bulk | |
| Connector Style | SSMA | |
| Connector Type | Plug, Male Pin | |
| Contact Termination | Solder | |
| Shield Termination | Crimp | |
| Impedance | 50 Ohm | |
| Mounting Type | Free Hanging (In-Line), Right Angle | |
| Cable Group | RG-174, 188, 316 | |
| Fastening Type | Threaded | |
| Frequency - Max | 35GHz | |
| Features | Heat Shrink Tubing | |
| Housing Color | Silver | |
| Ingress Protection | - | |
| Body Material | Stainless Steel | |
| Body Finish | - | |
| Center Contact Material | Beryllium Copper | |
| Center Contact Plating | Gold | |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | |
| Voltage Rating | 250V | |
| Operating Temperature | -65°C ~ 165°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1045520-1 | |
| Related Links | 1045, 1045520-1 Datasheet, TE Connectivity Aerospace, Defense and Marine Distributor | |
