Weidmüller 1290350000
- Mfg. Part Number
- 1290350000
- Manufacturer
- Weidmüller
- Product Category
- Terminal Blocks - Headers, Plugs and Sockets
- Brief Description
- S2C-SMT 3.50/28/180LF 3.5SN BK
- Datasheet Download
- 1290350000.pdf
Availability of 1290350000
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 10.41167
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of 1290350000, we specialize in Weidmüller all series electronic components. 1290350000 can be shipped within 24 hours after order. If you have any demands for 1290350000, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- 1290350000 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
1290350000
| Internal Part Number | EIS-1290350000 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 30 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Headers, Plugs and Sockets | |
| Series | Omnimate S2C | |
| Packaging | Bulk | |
| Type | Header, Male Pins, Shrouded (4 Side) | |
| Number of Positions | 28 | |
| Positions Per Level | 14 | |
| Number of Levels | 2 | |
| Pitch | 0.138" (3.50mm) | |
| Header Orientation | Vertical | |
| Plug Wire Entry | - | |
| Termination Style | Solder | |
| Mounting Type | Through Hole | |
| Current - IEC | 13.4A | |
| Voltage - IEC | 200V | |
| Current - UL | 10A | |
| Voltage - UL | 150V | |
| Wire Gauge or Range - AWG | - | |
| Wire Gauge or Range - mm² | - | |
| Color | Black | |
| Operating Temperature | -50°C ~ 120°C | |
| Contact Mating Finish | Tin | |
| Features | Mating Flange, Solder Retention | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | 1290350000 | |
| Related Links | 12903, 1290350000 Datasheet, Weidmüller Distributor | |
1290350000 Details Description
